※HPLC methodology
GSH-60 applies HPLC(High-Performance Liquid Chromatography) to seperate HbA1c directly,resulting in dramatic inprovement in efficiency and precision.
HPLC methodology utilizes the isoelectric differences between different hemoglobin fractions to separate and quantify the HbA1c. HPLC method is the gold standard for measuring HbA1c and has been regarded as the consensus method by the National Glycohemoglobin Standardization Program(NGSP). GSH-60 is dual certificated by NGSP and IFCC.
※Features
■Accurate&Precise
l Excellent precision:CV≤1.5%
l Broader test range:2.8%-18.4%
l Goldsite self-developed high-performance column,Capable of separating different hemoglobin fractions.
■High Efficiency
l Test duration only for 1 min.
l STAT position supported.
l 110 sample positions with automatic loading function.
■Prolonged Lifespan
l Column can be reused for 8000 times.
l Smart liquid path washing system prevents unnecessary reagent-consuming.
l Upgraded reagent extends the life span of column.
■Easy Maintenance
l Daily maintenance conducted automatically by the machine.
l Power-saving auto wake-up when loading sample.
l 4-12 Mpa high pressure pump offers steady output and reduce pipe blockage.
l Compatible with barcode reader that facilitates reagent information management.
※Specifications
Principle | ·lon exchange ·High performance liquid chromatography(HPLC) | Configuration | ·LIS connection ·Communication USB port |
Analytes | HbA1c | Working Environment | 10-30℃ |
Sanple Types | Whole blood/diluted blood | Dimensions | 564mm*560mm*458mm |
Sample Volume | 3μL | Weight | 52kg |
Linear Correlation | r2≥0.99 | Power Supply | 100-240V,50/60Hz |
Reagent | Elution Buffer A\B\C, Hemolysis,HbA1c Calibrator | Throughput | 60T/hour |
Consumables | Column/Filter | Reaction temperature | 37±0.1℃ |
Others | ·Color LCD touch screen;Thermal Printer ·Reagent Barcode Reader | ||
