Species | Supporting cat, dog and rabbit, cow, horse and sheep +11 pre-defined programs mouse rat, gerbil, guinea pig, hamsters, totoro, hedgehog, ferret, monkey, pig，camel +20 self-programmed animals |
Parameters | 19 reportable parameters: WBC,Gran#, Lym# , Mid#,Gran%, Lym%,Mid%,RBC,HGB,HCT,MCV,MCH,MCHC, RDW-SD, RDW-CV, PLT,MPV, PDW, PCT 3 histograms for WBC,RBC and PLT |
Principles | lmpedance method for WBC, RBC and PLT test.Cyanide free colorimetry for HGB test |
Reagent | Diluent,Lytic Reagent |
Test mode | whole blood mode:17uL Pre-diluted mode: 20uL |
Throughput | up to 35 tests per hour |
Repeatability | WBC:≤3.0%(4.00-15.00x109/L RBC:≤2.0%(> 3.50x1012 /L) HGB:≤2.0%(110-180g/L) MCV:≤1.0%(70.0-110.0fL) PLT: for dog≤6.0%(100-500x109/L) for cat≤10.0%(100-500x109/L) |
Linearity range | WBC:0.00-200x109/L RBC: 0.00-17.00x1012/L HGB:0-250g/L PLT:0-3000x109/L HCT:0.0-67% |
Communication | Support bi-directional LIS |
Display | 10.4inches TFT touch screen |
Storage | up to 50,000 records |
Interface | 4 USB ports,1 LAN port |
Power requirement | 100V-240V~, 50/60Hz,≤200VA |
Net weight | 26kg |
Dimension | 362mm*427mm"470mm |
Friendly to vets
·Small footprint&built-in lyse
Make space-use more efficient in vet lab
·10.4" touch screen
Easy to operate and read
·Clear and intuitive interface
Click and test,easy to go
Powerful data management System
·50,000 records storage
·lnternational standard transfer protocol
·USB&LAN ports for data output
Affordable care
·Less reagent cost making more
informative bloodworks affordable
·2 reagents only,lyse inside
Exclusive software forvet use
·Multi-species modes available
·Strategic cooperation with leading acedemic veterinary institutions in China
·Software tailored-made for animals in particular
●Parameters
19 reportable parameters:
WBC,Gran#, Lym# , Mid#, Gran%,Lym%, Mid%,RBC,
HGB,HCT, MCV, MCH, MCHC,RDW-SD,RDW-CV,PLT,
MPV,PDW,PCT 3 histograms for WBC, RBC and PLT
●Throughput
up to 35 tests per hour
